Images may be representations. Actual product may vary.
| Core Size: | 24.13 x 19.24 x 2.68 |
| Tube Size: | 1.25" (MegaCool) |
| Rows: | 2 |
| Overall Size: | 27.13 x 19.25 |
| Flow Direction: | CrossFlow |
| Inlet / Outlet: | Top Passenger / Bottom Driver |
| Trans Cooler: | No (N/A) |
| Important Note: | Thick Radiator, May require modifications to fit, External Transmission Cooler Needed for Automatic |
| Fan Size: | Twin 11 (in) 1510 CFM total |
| Total Thickness: | 5.46 (Rad + Fan) |
| Availability: | In Stock |
A "one stop shop" for all of your cooling needs. We have paired this radiator with a high performance electric fan and a hand formed aluminum fan shroud. This ensures optimal airflow across the entire core surface area.
